C#.Net用户自定义控件制作教程

/// <summary>
/// C#.Net 设计用户自定义控件
/// C#制作用户自定义控件
/// </summary>
/// </summary>
[ToolboxBitmap(typeof(CustomControl.ucButton), "ucButton.bmp")]
public partial class ucButton : UserControl
{
   private bool _IsFocused = false; //标记按钮是否为焦点状态

   public ucButton()
   {
      InitializeComponent();

      this.DoHideFocusedTag();
      this.MyCatpionText = this.Name;
   }

   private EventHandler _OnButtonClick = null;

   private string _MyCatpionText = "ucButton1";

   /// <summary>
   /// 按钮标题
   /// </summary>
   [EditorBrowsable(EditorBrowsableState.Always)]
   [Browsable(true)]
   [DefaultValue("ucButton1")]
   public string MyCatpionText
   {
      get { return _MyCatpionText; }
      set { _MyCatpionText = value; lblCaption.Text = _MyCatpionText; }
   }

   /// <summary>
   /// 用户自定义Click事件
   /// </summary>
   [EditorBrowsable(EditorBrowsableState.Always)]
   [Browsable(true)]
   public event EventHandler OnButtonClick
   {
      add { _OnButtonClick += new EventHandler(value); }
      remove { _OnButtonClick -= new EventHandler(value); }
   }

   private void lblCaption_Click(object sender, EventArgs e)
   {
      //转移Click事件, 触发用户自定义事件
      if (_OnButtonClick != null) _OnButtonClick(this, e);
   }

   private void lblCaption_MouseDown(object sender, MouseEventArgs e)
   {
      if (_IsFocused)
      {
         lblCaption.Font = new Font(lblCaption.Font.FontFamily, lblCaption.Font.Size, FontStyle.Bold);
      }
   }

   private void lblCaption_MouseUp(object sender, MouseEventArgs e)
   {
      if (_IsFocused)
      {
         lblCaption.Font = new Font(lblCaption.Font.FontFamily, lblCaption.Font.Size, FontStyle.Regular);
      }
   }

   private void ucButton_SizeChanged(object sender, EventArgs e)
   {
      lblUnderLine.Top = this.Height - 1;
      lblUnderLine.Width = this.Width - 15;
   }

   /// <summary>
   /// 还原按钮状态
   /// </summary>
   public void DoHideFocusedTag()
   {
      this.pictureBox1.Image = global::vjsdn.CustomControl.Properties.Resources.GrayTag;
      this.lblUnderLine.Visible = false;
      lblCaption.ForeColor = Color.Black;
   }

   /// <summary>
   /// 设计按钮为焦点状态
   /// </summary>
   public void DoShowFocusedTag()
   {
      this.pictureBox1.Image = global::vjsdn.CustomControl.Properties.Resources.FosedTag;
      this.lblUnderLine.Visible = true;
      lblCaption.ForeColor = Color.Blue;
   }

   private void ucButton_MouseEnter(object sender, EventArgs e)
   {
      if (this.Parent != null)
      {
         foreach (Control c in this.Parent.Controls)
         {
            if (c is ucButton) (c as ucButton).DoHideFocusedTag();
         }
      }

      this.DoShowFocusedTag();
      _IsFocused = true;
   }

   [EditorBrowsable(EditorBrowsableState.Always)]
   [Browsable(true)]
   [Description("")]
   public Label MyCaption
   {
      get { return lblCaption; }
   }

   private void lblCaption_MouseEnter(object sender, EventArgs e)
   {
      this.ucButton_MouseEnter(sender, e);
   }

}
